Digital Audio Processor 16x16 with Dante

12x12 Analog Ports + 4x4 DANTE

• 12-ch balanced MIC/line inputs and 12-ch balanced line outputs
• 4x4 DANTE audio with primary and redundant network interfaces
• Total of 16 chanels of digital audio processing
• Support for adaptive feedback suppression function
• Supports the full-band adaptive acoustic echo cancellation technology
• Built in dynamic adaptive noise reduction technology to reduce noise up to 18dB
• Auto Mixer function with priority for multiple inputs in conference scenarios
• Standard DSP modules such as Expander, Equalizer, Compressor, Auto Gain Control, Limiter, High Pass Filter, Low Pass Filter and Delay
• Matrix router can send any input or DSP to any output or DSP
• Includes volume control, metering, and scene control
• 48V phantom power available for the 12-ch MIC inputs
• 48KHz sampling rate, 24-bit for A/D or D/A conversion
• Includes 8-ch GPIO for custom programmable functions or scene recalling
• Configuration via network interface, control software compatible with Win 7 and Win 10.
• Support RS-232 serial commands control
