HDMI KVM over IP (HDMI 1.3) with Video Wall

Specs:

• HDMI 1.3 and HDCP 1.4 compliant
• Video resolution up to 1920x1200@60Hz 4:4:4
• Support 4.95Gbps video bandwidth
• Signal transmission distance can be extended up to 328ft / 100m via Cat 5e/6/6A/7 cable
• Support point-to-point signal extension
• Support signal distribution, multicast mode, distributed matrix and video wall (up to 9 x 9) functions over a 1G Network Switch
• Intelligent video wall management makes it achievable of novel layout of wall configurations
• Support LPCM 2.0CH (32/44.1/48KHz) audio format
• Encoder supports HDMI local loop output
• Support audio embedding and extracting
• Support USB/KVM function (one to one & one to many), and bidirectional IR/RS-232 control (pass-through & Guest mode)
• Support main stream and sub stream encoding modes
• Stream parameters can be configured via Web GUI or Controller Box
• Controlled via panel buttons, IR, RS-232, TCP/IP, Web GUI and Controller Box
• Support PoE function (802.3af Class 3, PD mode)
• Smart networking design for easy and flexible installation
